InteliATS
NT
PWR, SW version 2.5, ©ComAp – May 2015 9
IA-NT- PWR-2.5-Reference Guide.pdf
Configurability
One of the key features of the controller is high level of adaptability of the system to the needs of
every particular application. The way, how to achieve this, is the configuration.
NOTE:
Use LiteEdit PC software to read configuration from the controller or disk, view it, modify it and write
the configuration to controller or disk.
The firmware contains a number of binary inputs and outputs needed for all necessary functions
available in the firmware. But not all functions are required at the same time on different gen-sets and
also the controller hardware does not have so many input and output terminals. One of the main tasks
of the configuration is mapping of "logical" firmware inputs and outputs to the "physical" hardware
inputs and outputs.
Configuration parts:
1. Mapping of logical binary inputs (functions) or assigning alarms to physical binary input
terminals
2. Mapping of logical binary outputs (functions) to physical binary output terminals
3. Changing language of the controller texts
The controller is delivered with a default configuration, which should fit to most standard
applications. This default configuration can be changed only using PC and LiteEdit software. See
LiteEdit documentation for details.
NOTE:
You need one of communication modules to connect the controller to a PC with LiteEdit. There is a
special easy removable service module for cases, where there is no communication module
permanently attached.
Once the configuration is modified, it can be stored in a file for later usage with another controller or
for backup purposes. The file is called archive and has file extension ".ail". An archive contains full
image of the controller at the moment of saving (if the controller is online to the PC) except firmware,
i.e. besides configuration there are also current adjustment of all setpoints, all measured values, a
copy of history log and a copy of alarm list.
The archive can be simply used for cloning of controllers, which means preparing controllers with
identical configuration and settings.
