ComAp InteliATS PWR User Manual

InteliATS
NT
PWR, SW version 2.5, ©ComAp – May 2015 69
IA-NT- PWR-2.5-Reference Guide.pdf
Gen V Del [s]
Delay for generator under voltage and overvoltage alarm
Step: 0.1 s
Range: 0.0 – 600.0 s
Volt Unbal Trp [%]
Threshold for generator voltage unbalance alarm.
Step: 1% of Nominal voltage
Range: 0 – 200% of Nominal voltage
Volt Unbal Del [s]
Delay for generator voltage unbalance alarm.
Step: 0.1 s
Range: 0.0 – 600.0 s
Gen >Freq Trp [%]
Threshold for generator phase L3 over frequency.
Step: 0.1% of Nominal frequency
Range: 0 (Gen <Freq Trp) – 200.0% of Nominal frequency
Gen <Freq Trp [%]
Threshold for generator phase L3 under frequency.
Step: 0.1% of Nominal frequency
Range: 0.0 – 200 (Gen >Freq Trp) % of Nominal frequency
Gen Freq Del [s]
Delay for generator under frequency and over frequency alarm.
Step: 0.1 s
Range: 0.0 – 600.0 s
Programmable delay on alarms
Possibility to set programmable delay on alarms configured for binary input 6 and 7 has been added. If
set, it blocks alarms of the respective binary input for the whole time the delay is active. If the reason
for the alarm persists after the delay time expired, the alarm is activated. If not, the alarm does not
appear. This feature allows the user to perform “filtering” of alarms within a specified period of time.
The delay length can be set via the following setpoints:
BI6 Delay [s]
Delay for alarm on binary input nr. 6
Step: 0.1 s
Range: 0 – 360.0 s
BI7 Delay [s]
Delay for alarm on binary input nr. 7
Step: 0.1 s
Range: 0 – 360.0 s
AMF Settings
RetFromIsland [MANUAL, AUTO]
MANUAL: After closing GCB, IA-NT goes to MAN Mode automatically.
AUTO: No automatic switching to MAN Mode.
