NOTE:
For details on all IA-NT extension and communication modules see IL-NT, IC-NT, IA-NT, ID-Lite-
Accessory Modules manual.
IL-NT RS232-485 interface (optional card)
Plugs into IA-NT controller COMMUNICATION MODULE port.
Maximal distance 10m (RS232), 1200m (RS485)
Maximum Speed Up to 57.6 kBd (DIRECT), 38.4kBd Analog
modem, 9.6 kBd digital modem, 57.6 kBd
(MODBUS)
IL-NT S-USB interface (optional card)
Plugs into IA-NT controller COMMUNICATION MODULE port.
Maximal distance 5m
Maximum Speed Up to 57.6 kBd (DIRECT), 38.4kBd Analog
modem, 9.6 kBd digital modem, 57.6 kBd
(MODBUS)
Use only shielded A-B USB cables up to 5m length.
Recommend USB cable:
USB-LINK CABLE 1.8M – ComAp A-B USB cable.
IB-Lite interface (optional card)
Plugs into IA-NT controller COMMUNICATION MODULE port.
Interface to Ethernet RJ45 (10baseT)
Operating temperature -30..+70
o
C
Storage temperature -30..+70
o
C
IL-NT-GPRS interface (optional card)
Plugs into IA-NT controller COMMUNICATION MODULE port.
SIM Card Type Standard size (1FF)
Antenna Connector SMA Female
IL-NT AOUT8 interface (optional card)
Plugs into IA-NT controller EXTENSION MODULE port.
Number of PWM outputs 8
PWM frequency 250Hz
Maximum current 0.5 A
Maximum switching voltage 36 VDC
Output resistance 1Ω
Resolution 10 bits
