InteliATS
NT
PWR, SW version 2.5, ©ComAp – May 2015 45
IA-NT- PWR-2.5-Reference Guide.pdf
Binary inputs IA-NT - default
BI1 GCB Feedback
BI2 MCB Feedback
BI3 GenReadyToLoad
BI4 MainsFailBlock
BI5 Remote Transfer
BI6 Remote TEST
BI7 Remote TEST OnLd
Binary inputs – list
Rem Start/Stop
External request for engine run. AUT mode only.
NOTE:
If the binary input Rem Start/Stop is active and mains failure occurs, the MCB breaker opens and after
the Trans Del delay the GCB breaker is closed. Once the mains is OK, the MainsReturnDel delay
elapses and the GCB breaker is opened. Then after the Trans Del delay is MCB breaker closed. Gen-
set remains running as long as Rem Start/Stop is active. See AMF time chart for more details.
Rem Transfer
External request for an immediate transfer from mains to generator without waiting for the AMF
Settings: EmergStart Del has elapsed. In the case the transfer not succeeded the system will stay in
neutral position. The MainsFailBlock input performs its work normally.
GCB Feedback
Use this input for indication, whether the generator circuit breaker is open or closed.
If the feedback is not used, connect this input to the output GCB CLOSE/OPEN
MCB Feedback
This input indicates whether MCB is closed or opened.
Emergency Stop
If the input is opened, Trip is immediately activated. Stop signal for the gen-set is sent and the GCB is
opened.
Access Lock
If the input is closed, no setpoints can be adjusted from controller front panel and gen-set mode (OFF-
MAN-AUT-TEST) cannot be changed.
NOTE:
Access Lock does not protect setpoints and mode changing from LiteEdit. To avoid unqualified
changes the selected setpoints can be password protected. Also the button Fault reset, is not blocked
at all and buttons Start and Stop in MAN mode are not blocked.
