ComAp InteliATS PWR User Manual

InteliATS
NT
PWR, SW version 2.5, ©ComAp – May 2015 111
IA-NT- PWR-2.5-Reference Guide.pdf
IL-NT BIO8 extension module (optional card)
Technical details:
IL-NT BIO8 plugs into the controller’s EXTENSION MODULE port.
8 dedicated pins of the plug-in card’s terminal can be configured as binary inputs or outputs.
Binary inputs
Number of inputs 8
Input resistance 4.7 kΩ
Input range 0–36 VDC
Voltage level for close contact indication (Logical 1) < 0.8 VDC
Voltage level for open contact indication (Logical 0) > 2 VDC
Max voltage level for open contact indication 8–36 VDC
Binary open collector outputs
Number of outputs 8
Maximum current per pin 0.5 A
Maximum switching common current 2 A
Maximum switching voltage 36 VDC
HINT:
Binary inputs are not galvanically isolated.
