ComAp InteliATS PWR User Manual

InteliATS
NT
PWR, SW version 2.5, ©ComAp – May 2015 50
IA-NT- PWR-2.5-Reference Guide.pdf
Mains On Load
(LBO) Mains On Load <= (LBO) Mains Healthy and (LBI) MCB Feedback OK
AL Gen >V
The output closes if the generator overvoltage Trip alarm activates.
The output opens, if
 alarm is not active and
 FAULT RESET is pressed
AL Gen <V
The output closes if the generator under voltage Trip alarm activates.
The output opens, if
 alarm is not active and
 FAULT RESET is pressed
AL Gen Volts
The output closes if the generator over/under voltage alarm or voltage asymmetry alarm activates.
The output opens, if
 alarm is not active and
 FAULT RESET is pressed
AL Gen Freq
Output closes if the generator over/under frequency alarm activates.
The output opens, if
 alarm is not active and
 FAULT RESET is pressed
AL Gen >Freq
Output closes if the generator over frequency alarm activates.
The output opens, if
 alarm is not active and
 FAULT RESET is pressed
AL Gen <Freq
Output closes if the generator under frequency alarm activates.
The output opens, if
 alarm is not active and
 FAULT RESET is pressed
AL Mains Volts
The output closes if the mains over/under voltage alarm or voltage asymmetry alarm activates.
The output opens, if
 alarm is not active
AL Mains Freq
Output closes if the mains over/under frequency alarm activates.
The output opens, if
 alarm is not active
AL Overload Sd
Output closes if the generator overload alarm activates.
The output opens, if
 alarm is not active and
 FAULT RESET is pressed
