Setpoint group ATTsettings Related FW 2.5.0
Range [units] -10000 .. +10000 [-]
Default value 80 YES
Step 1
Comm object 11852 Related applications
Description
Regulator requested value.
Value of this Setpoint should be given in value of quantity without decimal point.
Example: When AIN is configured in such way that Load limit set on 5V to maintain the value
8.54bar, then the value inserted to this Setpoint is 854.
LoadRequest 1
6 back to List of setpoints
Setpoint group ATTsettings Related FW 2.5.0
Range [units] -10000 .. +10000 [-]
Default value 80 YES
Step 1
Comm object 11853 Related applications
Description
Regulator requested value when LOADREQUEST2 (PAGE 191) is active.
Value of this Setpoint should be given in value of quantity without decimal point.
Example: When AIN is configured in such way that Load limit set on 5V to maintain the value
8.54bar, then the value inserted to this Setpoint is 854.
Load request 2
6 back to List of setpoints
Setpoint group ATTsettings Related FW 2.5.0
Range [units] 1 .. 10000 [1/s]
Default value 1000 YES
Step 1
Comm object 11854 Related applications
Description
Ramp when is switched between LoadRequest 1 (page 133) and Load request 2 (page 133).
LoadReq Ramp
6 back to List of setpoints
