New user setpoint
Existing user setpoint
Text input for Alarm / History message
If user protection state is checked then created user protection has LBO located in Bin Values
in the Group:User Protection States (page 422).
Protection states
Protection states are states of fixed and user protections. These states can be configured as binary output or
used in PLC logic.
Fixed protection states
Important Fixed Protections (page 119) have a protection state. The protection state is (usually) named the
same as the alarm. Fixed protection states are in a group of 32 values.
Protection states groups:
FIXED PROTECTIONS STATES 1 (PAGE 421)
FIXED PROTECTIONS STATES 2 (PAGE 421)
FIXED PROTECTIONS STATES 3 (PAGE 421)
FIXED PROTECTIONS STATES 4 (PAGE 421)
FIXED PROTECTIONS STATES 5 (PAGE 422)
User protections states
During the Configuration of protections in InteliConfig (page 126), you can decide whether you want to
add user protection state for the protection. The name is the same as the alarm's message.
User protection states are in a group of 32 values.
Note: Group of User protection states is showed only when there is at least 1 protection state in it.
Protection states group:
USER PROTECTIONS STATES 1 (PAGE 422)
Alarm management
The controller evaluates two levels of alarms. Level 1 – yellow alarm – is a pre-critical alarm that is only
informative and does not take any action regarding Gen-set control. Level 2 – red alarm – represents a critical
situation, where an action must be taken to prevent damage of the Gen-set or technology.
