InteliLite4 AMF20 Global Guide
267
Subgroup: Frequency Protection
Generator Overfrequency BOC
Setpoint group Generator settings Related FW 1.3.0
Range [units] Generator Overfrequency Wrn (page 267) .. 200,0 [%]
Default value 110,0 % Alternative config NO
Step 0,1 % of Nominal Frequency (page 215)
Comm object 8296 Related applications AMF,MRS
Config level Standard
Setpoint visibility Always
Description
Threshold for generator phase L1 overfrequency.
Note: When there is no control of breakers, the type of protection is Sd not BOC.
6 back to List of setpoints
Generator Overfrequency Wrn
Setpoint group Generator settings Related FW 1.3.0
Range [units]
Generator Underfrequency Wrn (page 267) .. Generator Overfrequency BOC
(page 267) [%]
Default value 110,0 % Alternative config NO
Step 0,1 % of Nominal Frequency (page 215)
Comm object 9688 Related applications AMF,MRS
Config level Standard
Setpoint visibility Always
Description
Threshold for generator phase L1 overfrequency.
6 back to List of setpoints
Generator Underfrequency Wrn
Setpoint group Generator settings Related FW 1.3.0
Range [units]
Generator Underfrequency BOC (page 268) .. Generator Overfrequency Wrn
(page 267) [%]
Default value 85,0 % Alternative config NO
Step 0,1 % of Nominal Frequency (page 215)
Comm object 9689 Related applications AMF,MRS
Config level Standard
Setpoint visibility Always
Description
Threshold for generator phase L1 underfrequency.
6 back to List of setpoints
