InteliLite4 AMF20 Global Guide
266
Generator <> Voltage Delay
Setpoint group Generator settings Related FW 1.3.0
Range [units] 0,0 .. 600,0 [s]
Default value 3,0 s Alternative config NO
Step 0,1 s
Comm object 9103 Related applications AMF,MRS
Config level Standard
Setpoint visibility Always
Description
Delay for Generator Overvoltage Sd (page 264), Generator Overvoltage Wrn (page 264), Generator
Undervoltage BOC (page 265) and Generator Undervoltage Wrn (page 265) protection.
6 back to List of setpoints
Voltage Unbalance BOC
Setpoint group Generator settings Related FW 1.3.0
Range [units]
1 .. 200 [%] of Nominal Voltage Ph-Ph (page 211) or Nominal Voltage Ph-N
(page 211)
Default value 10 % Alternative config NO
Step 1 %
Comm object 8288 Related applications AMF,MRS
Config level Advanced
Setpoint visibility Conditioned by the setpoint Connection type (page 209)
Description
Threshold for generator voltage unbalance alarm.
Note: When there is no control of breakers, the type of protection is Sd not BOC.
6 back to List of setpoints
Voltage Unbalance BOC Delay
Setpoint group Generator settings Related FW 1.3.0
Range [units] 0.0 .. 600.0 [s]
Default value 3.0 s Alternative config NO
Step 0.1 s
Comm object 8289 Related applications AMF,MRS
Config level Advanced
Setpoint visibility Conditioned by the setpoint Connection type (page 209)
Description
Delay for Voltage Unbalance BOC (page 266) protection.
6 back to List of setpoints
