InteliLite4 AMF20 Global Guide
264
Subgroup: Voltage Protection
Generator Overvoltage Sd
Setpoint group Generator settings Related FW 1.3.0
Range [units] Generator Overvoltage Wrn (page 264) .. 200 [%]
Default value 110 % Alternative config NO
Step 1 % of Nominal Voltage Ph-N (page 211) or Nominal Voltage Ph-Ph (page 211)
Comm object 8291 Related applications AMF,MRS
Config level Standard
Setpoint visibility Always
Description
Threshold for generator overvoltage protection. All three phases are checked. Maximum out of three is
used.
Note: Phase to phase and phase to neutral voltages are used for this protection.
6 back to List of setpoints
Generator Overvoltage Wrn
Setpoint group Generator settings Related FW 1.3.0
Range [units]
Generator Undervoltage Wrn (page 265) .. Generator Overvoltage Sd (page
264) [%]
Default value 110 % Alternative config NO
Step 1 % of Nominal Voltage Ph-N (page 211) or Nominal Voltage Ph-Ph (page 211)
Comm object 9686 Related applications AMF,MRS
Config level Standard
Setpoint visibility Always
Description
Threshold for generator overvoltage protection. All three phases are checked. Maximum out of three is
used.
Note: Phase to phase and phase to neutral voltages are used for this protection.
6 back to List of setpoints
