InteliLite4 AMF20 Global Guide
265
Generator Undervoltage Wrn
Setpoint group Generator settings Related FW 1.3.0
Range [units]
Generator Undervoltage BOC (page 265) .. Generator Overvoltage Wrn (page
264) [%]
Default value 70 % Alternative config NO
Step 1 % of Nominal Voltage Ph-N (page 211) or Nominal Voltage Ph-Ph (page 211)
Comm object 9687 Related applications AMF,MRS
Config level Standard
Setpoint visibility Always
Description
Threshold for generator undervoltage protection. All three phases are checked. Minimum out of three is
used.
Note: Phase to phase and phase to neutral voltages are used for this protection.
6 back to List of setpoints
Generator Undervoltage BOC
Setpoint group Generator settings Related FW 1.3.0
Range [units] 0 .. Generator Undervoltage Wrn (page 265) [%]
Default value 70 % Alternative config NO
Step 1 % of Nominal Voltage Ph-N (page 211) or Nominal Voltage Ph-Ph (page 211)
Comm object 8293 Related applications AMF,MRS
Config level Standard
Setpoint visibility Always
Description
Threshold for generator undervoltage protection. All three phases are checked. Minimum out of three is
used.
Note: Phase to phase and phase to neutral voltages are used for this protection.
Note: When there is no control of breakers, the type of protection is Sd not BOC.
6 back to List of setpoints
