InteliLite4 AMF20 Global Guide
211
SplPhL1L2
L1 >=100 V
L2 >= 100 V
L3 <= 20 V
Mono Phase
L1 >=100 V
L2 <= 20 V
L3 <= 20 V
Voltage Autodetect shutdown
6 back to List of setpoints
Nominal Voltage Ph-N
Setpoint group Basic settings Related FW 1.3.0
Range [units] 80 .. 20 000 [V]
Default value 231 V Alternative config YES
Step 1 V
Comm object 8277 Related applications AMF,MRS
Config level Standard
Setpoint visibility Conditioned by the setpoint Connection type (page 209).
Description
Nominal voltage (phase to neutral).
Note: To lock this setpoint against editing you also have to lock setpoint Nominal Voltage Ph-N 1
(page 373), Nominal Voltage Ph-N 2 (page 378) and Nominal Voltage Ph-N 3 (page 383).
6 back to List of setpoints
Nominal Voltage Ph-Ph
Setpoint group Basic settings Related FW 1.3.0
Range [units] 80 .. 40 000 [V]
Default value 400 V Alternative config YES
Step 1 V
Comm object 11657 Related applications AMF,MRS
Config level Standard
Setpoint visibility Conditioned by the setpoint Connection type (page 209).
Description
Nominal system voltage (phase to phase).
Note: To lock this setpoint against editing you also have to lock setpoint Nominal Voltage Ph-Ph 1
(page 373), Nominal Voltage Ph-Ph 2 (page 378) and Nominal Voltage Ph-Ph 3 (page 383).
6 back to List of setpoints
