InteliLite4 AMF20 Global Guide
212
Nominal Voltage 3Ph Low Y
Setpoint group Basic settings Related FW 1.3.0
Range [units] 80 .. 20 000 [V]
Default value 120 V Alternative config YES
Step 1 V
Comm object 20811 Related applications AMF,MRS
Config level Standard
Setpoint visibility
Visible if one of the three Connection type (page 209) Setpoints is set to
Autodetect.
Description
This setting is used as phase-neutral Nominal Voltage Ph-N (page 211) by the voltage autodetect
function, if detected Connection type (page 209) is 3Ph Low Y (controller can not distinguish between
the 4 wire and 3 wire connection), detected phase-phase voltage is lower than 300V in all three phases
and phase-neutral voltage is lower than or equal to 160V in all three phases.
6 back to List of setpoints
Nominal Voltage 3Ph High Y
Setpoint group Basic settings Related FW 1.3.0
Range [units] 80 .. 20 000 [V]
Default value 277 V Alternative config YES
Step 1 V
Comm object 20812 Related applications AMF,MRS
Config level Standard
Setpoint visibility
Visible if one of the three Connection type (page 209) Setpoints is set to
Autodetect.
Description
This setting is used as phase-neutral Nominal Voltage Ph-N (page 211) by the voltage autodetect
function, if detected Connection type (page 209) is 3Ph High Y, detected phase-phase voltage is higher
than or equal to 300V in all three phases and phase-neutral voltage is higher than 160V in all three
phases.
6 back to List of setpoints
