Nominal Voltage High Leg D
Setpoint group Basic settings Related FW 1.3.0
Range [units] 80 .. 20 000 [V]
Default value 277 V Alternative config YES
Step 1 V
Comm object 20813 Related applications AMF,MRS
Config level Standard
Setpoint visibility
Visible if one of the three Connection type (page 209) Setpoints is set to
Autodetect.
Description
This setting is used as phase-neutral Nominal Voltage Ph-N (page 211) by the voltage autodetect
function, if detected Connection type (page 209) is High Leg D. Set this setpoint to 120V with high leg
delta system, which works with the high leg voltage 208V (L2-N).
6 back to List of setpoints
Nominal Voltage SplitPhase
Setpoint group Basic settings Related FW 1.3.0
Range [units] 80 .. 20 000 [V]
Default value 120 V Alternative config YES
Step 1 V
Comm object 20814 Related applications AMF,MRS
Config level Standard
Setpoint visibility
Visible if one of the three Connection type (page 209) Setpoints is set to
Autodetect.
Description
This setting is used as phase-neutral Nominal Voltage Ph-N (page 211) by the voltage autodetect
function, if detected Connection type (page 209) is SplPhL1L2 or SplPhL1L3.
