InteliLite4 AMF20 Global Guide
214
Nominal Voltage MonoPhase
Setpoint group Basic settings Related FW 1.3.0
Range [units] 80 .. 20 000 [V]
Default value 120 V Alternative config YES
Step 1 V
Comm object 20815 Related applications AMF,MRS
Config level Standard
Setpoint visibility
Visible if one of the three Connection type (page 209) Setpoints is set to
Autodetect.
Description
This setting is used as phase-neutral Nominal Voltage Ph-N (page 211) by the voltage autodetect
function, if detected Connection type (page 209) is MonoPhase.
6 back to List of setpoints
Gen VT Ratio
Setpoint group Basic settings Related FW 1.3.0
Range [units] 0.1 .. 500.0 [V/V]
Default value 1.0 V/V Alternative config NO
Step 0.1 V/V
Comm object 9579 Related applications AMF,MRS
Config level Advanced
Setpoint visibility Always
Description
Generator voltage potential transformers ratio. If no VTs are used, adjust this setpoint to 1.
6 back to List of setpoints
Mains VT Ratio
Setpoint group Basic settings Related FW 1.3.0
Range [units] 0.1 .. 500.0 [V/V]
Default value 1.0 V/V Alternative config NO
Step 0.1 V/V
Comm object 9580 Related applications AMF
Config level Advanced
Setpoint visibility Conditioned by the setpoint Default Application Select (page 217)
Description
Mains voltage potential transformers ratio. If no VTs are used, adjust the setpoint to 1.
6 back to List of setpoints
