InteliLite4 AMF20 Global Guide
479
Gas:
The output closes together with binary output IGNITION (PAGE 487) when engine RPM exceed 30 RPM (fix
value).
Image 8.34 Fuel Solenoid 3
The output is deactivated when:
Emergency Stop comes
Cooled Gen-set is stopped
In pause between repeated starts
6 back to Logical binary outputs alphabetically
LBO: G
Related FW 1.3.0 Related applications AMF,MRS
Comm object 35
Description
This output provides 1s pulse when:
GCB button is pressed on the controller front facia or
GCB button is pressed on any of external local/remote terminals or
GCB command is received via communication line or
the input GCB BUTTON is activated.
GCB Button Echo
6 back to Logical binary outputs alphabetically
Related FW 1.3.0 Related applications AMF,MRS
Comm object 2698
Description
LBO is active as long as it's button is pressed or it's LBI is active.
GCB Button State
6 back to Logical binary outputs alphabetically
