InteliLite Global Guide
192
Setpoint group Basic settings Related FW 1.9.0
Range [units] 1 .. 5 000 [A/5A]
Default value 2 000 A/5A Alternative config NO
Step 1 A/5A
Comm object 8274 Related applications AMF, MRS
Config level Standard
Setpoint visibility Always
Description
Gen-set current transformers ratio.
Note: Generator currents and power measurement is suppressed if current level is below 1% of CT
range.
CT Ratio
6 back to List of setpoints
Setpoint group Basic settings Related FW 1.9.0
Range [units] Load / GenSet/ None [-]
Default value Gen-set Alternative config NO
Step [-]
Comm object 11625 Related applications AMF, MRS
Config level Advanced
Setpoint visibility Always
Description
Adjustment of location of current measurement.
Load: Current CT´s are physically placed on Load (typically between GCB and MCB)
GenSet: Current CT´s are physically placed on GenSet (typically before GCB)
None: There are no current CT´s.
When option None is selected, following objects are hidded/changed:
Current screen is hidden
Generator Power screen is hidden
Statistics screens - values Genset kWh, Genset kVArh, Mains kWh and Mains kWArh are hidden
Mains screen - kW meter is replaced by generator voltage meter
Generator L1-N voltage is displayed for Monopahse, Splitphase L1L2, Splitphase L1L3 and High
Leg delta connection types
Generator L1-L2 voltage is displayed for 3ph3w and 3ph4w connection types
Group Load is hidden
Group Statistics - values Genset kWh, Genset kVArh, Mains kWh and Mains kWArh are hidden
Note: For more details about this function see chapter CT Location (page 29).
CT Location
6 back to List of setpoints
