InteliLite Global Guide
242
Group: Generator settings
Subgroup: Overload Protection
Setpoint group Generator settings Related FW 1.9.0
Range [units] Overload Wrn (page 242) .. 200 [%]
Default value 120 % Alternative config NO
Step 1 % of Nominal Power (page 191)
Comm object 8280 Related applications AMF, MRS
Config level Standard
Setpoint visibility Always
Description
Threshold level for generator overload (in % of Nominal power) protection. Protection is BOC (Breaker Open
and gen-set Cooldown).
Note: When there is no control of breakers, the type of protection is Sd not BOC.
Overload BOC
6 back to List of setpoints
Setpoint group Generator settings Related FW 1.9.0
Range [units] 0 .. Overload BOC (page 242) [%]
Default value 120 % Alternative config NO
Step 1 % of Nominal Power (page 191)
Comm object 9685 Related applications AMF, MRS
Config level Standard
Setpoint visibility Always
Description
Threshold level for generator overload (in % of Nominal power) protection. This is only warning.
Overload Wrn
6 back to List of setpoints
Setpoint group Generator settings Related FW 1.9.0
Range [units] 0,0 .. 600,0 [s]
Default value 5,0 s Alternative config NO
Step 0,1 s
Comm object 8281 Related applications AMF, MRS
Config level Standard
Setpoint visibility Always
Description
Delay for Overload BOC (page 242)Overload BOC (page 242) and Overload Wrn (page 242) protection.
Overload Delay
6 back to List of setpoints
