ComAp InteliLite AMF25 User Manual

InteliLite Global Guide
241
Setpoint group Dual Operation Related FW 1.9.0
Range [units] Monitoring / AL Indic / Wrn [-]
Default value AL Indic Alternative config NO
Step [-]
Comm object 16042 Related applications AMF, MRS
Config level Advanced
Setpoint visibility
Only if relevant module is installed + conditioned by the setpoint COM1 Mode (page
343) and COM2 Mode (page 345)
Description
This setpoint adjust the type of protection for Dual Operation Master Fail (page 665) alarm.
Master Error Protection
6 back to List of setpoints
Setpoint group Dual Operation Related FW 1.9.0
Range [units] Monitoring / AL Indic / Wrn [-]
Default value AL Indic Alternative config NO
Step [-]
Comm object 16043 Related applications AMF, MRS
Config level Advanced
Setpoint visibility
Only if relevant module is installed + conditioned by the setpoint COM1 Mode (page
343) and COM2 Mode (page 345)
Description
This setpoint adjust the type of protection for Dual Operation Slave Fail (page 665) alarm.
Slave Error Protection
6 back to List of setpoints
Setpoint group Dual Operation Related FW 1.9.0
Range [units] 0,0 .. 600,0 [s]
Default value 1,0 s Alternative config NO
Step 0,1 s
Comm object 8303 Related applications MRS
Config level Standard
Setpoint visibility Conditioned by the setpoint Operation Mode (page 183)
Description
Delay used in dual operation function. This delay is used when load from first gen-set is transferred to
second gen-set. Delay starts to countdown when GCB of first gen-set is open. When this delay countdown,
GCB of second gen-set is closed. This delay is important for correct function of external interlock.
Transfer Delay
6 back to List of setpoints

ComAp InteliLite AMF25 Specifications

General

Inputs	8 binary inputs
Outputs	8 binary outputs
Power Supply	8-36 V DC
Communication	RS232, RS485
Operating Temperature	-20°C to +70°C
Supported Generators	Diesel, gas
Controller Type	Automatic Mains Failure Controller
Protection	IP65
