ComAp InteliLite AMF25 User Manual

InteliLite Global Guide
527
LBI: E
Related FW 1.9.0 Related applications AMF, MRS
Comm object 951
Description
This binary input is used to switch on ECU POWER RELAY (PAGE 570), when engine start is not requested. It
is intended to enable engine values reading, when engine doesn't run.
When this binary input is active, binary output ECU POWER RELAY (PAGE 570) is active too.
When this binary input is inactive, function of ECU POWER RELAY (PAGE 570) is not affected.
ECU Key Switch
6 back to Logical binary inputs alphabetically
Related FW 1.9.0 Related applications AMF, MRS
Comm object 164
Description
This binary input is used to set the setpoint ECU Speed Adjustment (page 226) by binary inputs. When the
LBI is activated the setpoint is decreased by 2%.
ECU Speed Down
6 back to Logical binary inputs alphabetically
Related FW 1.9.0 Related applications AMF, MRS
Comm object 165
Description
This binary input is used to set the setpoint ECU Speed Adjustment (page 226) by binary inputs. When the
LBI is activated the setpoint is increase by 2%.
ECU Speed Up
6 back to Logical binary inputs alphabetically
Related FW 1.9.0 Related applications AMF, MRS
Comm object 45
Description
This input is designed to allow the gen-set or breakers to be controlled externally, not by the controller. This
feature can be useful in case of some failure, which disables the gen-set or breakers to be controlled by the
controller, but the gen-set itself is operational.
The controller behaves in the following way:
Shows the text EmergMan in the engine status on the main screen.
Stops all functions regarding the gen-set or breaker control, deactivates all outputs related to it.
Stop Fail alarm is not being evaluated and stop solenoid is not activated if nonzero speed is detected.
When the input is deactivated, the controller takes control according to the situation in the moment of
deactivation, i.e. the gen-set remains running loaded if it was running and GCB was closed in the
moment the input was deactivated.
Emergency MAN
6 back to Logical binary inputs alphabetically

ComAp InteliLite AMF25 Specifications

General

Inputs	8 binary inputs
Outputs	8 binary outputs
Power Supply	8-36 V DC
Communication	RS232, RS485
Operating Temperature	-20°C to +70°C
Supported Generators	Diesel, gas
Controller Type	Automatic Mains Failure Controller
Protection	IP65
