InteliLite Global Guide
534
LBI: O
Related FW 1.9.0 Related applications AMF, MRS
Comm object 43
Description
Binary input for OIL PRESSURE (PAGE 634) protection.
Monitoring Binary input is not used for protection or any other function. Signal is only
monitored.
HistRecOnl Binary input is not used for protection. Only history record is made if binary input is
active.
Wrn Binary input is used for warning protection only.
Sd Binary input is used for shutdown protection.
Protection types
IMPORTANT: This binary input is also used for evaluating engine running condition.
Example: Normally close connection - when LBI is closed then oil pressure is OK and is higher than
starting oil pressure.
Note: In case that you want to use binary input of oil pressure sensor just for protection please use one
of the BIN PROTECTION 1 (PAGE 500).
Oil Pressure
6 back to Logical binary inputs alphabetically
LBI: P
Related FW 1.9.0 Related applications AMF, MRS
Comm object 920
Description
This logic binary input enables or disables protections adjusted as LBI Enable.
Protection Enable
6 back to Logical binary inputs alphabetically
Related FW 1.9.0 Related applications AMF, MRS
Comm object 87
Description
This is the input of the Pulse Counter 1 function. The module counts pulses at the input and if the input
pulses counter reaches value given by the setpoint Conversion Coefficient Pulse 1 (page 222) the
counter value Pulse Counter 1 (page 470) is increased by 1 and input pulses counter is reset to 0. Both
counter value and input pulses counter are stored in the nonvolatile memory.
Pulse Counter 1
6 back to Logical binary inputs alphabetically
