InteliLite Global Guide
583
Image 8.178 Ignition 1
Image 8.179 Ignition 2
6 back to Logical binary outputs alphabetically
Related FW 1.9.0 Related applications AMF, MRS
Comm object 1257
Description
This input is on since start button is pressed till the unit is completely stopped (or the engine doesn’t start or
Sd or E-Stop becomes active)
Note: This function is the same as ECU POWER RELAY (PAGE 570) . Ignition ON stays there from
historical reasons.
Ignition On
6 back to Logical binary outputs alphabetically
