InteliLite Global Guide
582
LBO: I
Related FW 1.9.0 Related applications AMF, MRS
Comm object 39
Description
This output is used for switching between idle speed and nominal speed of the engine during the startup
phase, if this feature (input) is available on the particular engine. In the case of some EFI engines, the
idle/nominal switching is performed over the communication bus.
The output Idle/Nominal closes after the timer Idle Time (page 198) elapses. The Idle Time (page 198)
starts to countdown when Starting RPM (page 191) reached. The underspeed protection is not evaluated
during fixed 5 seconds period after reaching Starting RPM (page 191). A Start Fail protection occurs if the
RPM drop below 2RPM during idle.
Image 8.177 Idle/Nominal
Note: Connect binary output Idle/Nominal to speed governor to switch the speed:
opened = Idle
closed = Nominal
(for normally open contact type)
Idle/Nominal
6 back to Logical binary outputs alphabetically
Related FW 1.9.0 Related applications AMF, MRS
Comm object 37
Description
This output is dedicated to controlling the ignition at a gas engine. The output is closed together with binary
output FUEL SOLENOID (PAGE 572) in the moment when the timer Sd Ventilation Time (page 202) elapsed
and the gen-set reaches at least 30 RPM during cranking. The timer Sd Ventilation Time (page 202)
become active when the gen-set has been stopped for any Sd protection or the controller has been turned on
only before first cranking attempt. The output is opened 500ms after all Additional running engine indication
Additional running engine indications (page 117) will be inactive. The output is opened when the gen-
set has to be stopped or in pause during repeated starts.
Ignition
