InteliLite Global Guide
69
5.3 Operator Guide
5.3.1 Front panel elements 69
5.3.2 Display screens and pages structure 71
5.3.3 Browsing alarms 84
5.3.4 Password 85
5.3.5 Information screen 91
5.3.6 Language selection 92
5.3.7 Display contrast adjustment 93
5.3.1 Front panel elements
Image 5.12 Operator interface of AMF25
Control buttons
Position Picture Description
LEFT button. Use this button to move left or to change the mode. The button can
change the mode only if the main screen with the indicator of currently selected
mode is displayed.
Note: This button will not change the mode if the controller mode is forced by
one of binary inputs listed in the Reference Guide – “Operating modes” chapter.
RIGHT button. Use this button to move right or to change the mode. The button can
change the mode only if the main screen with the indicator of currently selected
mode is displayed.
