InteliLite Global Guide
731
8.3.1 Plug-In modules
Communication modules 731
Extension modules 743
IMPORTANT: 2nd generation of InteliLite controllers does not support new modules and 3rd
generation does not support all old modules.
The available communication plug-in modules are:
CM-RS232-485 - communication module for connection via RS232 or RS485 line
CM-4G-GPS - communication module for connection via 4G
CM-GPRS - communication module for connection via GPRS
CM-Ethernet - communication module for internet connection via Ethernet
The available extension plug-in modules are:
EM-BIO8-EFCP - extension module with 8 binary inputs/outputs and with earth fault current protection
Note: Controller has 2 plug-in module slots.
Module CM-Ethernet CM-4G-GPS CM-GPRS CM-RS232-485 EM-BIO8-EFCP
CM-Ethernet
CM-4G-GPS
CM-GPRS
CM-RS232-485
EM-BIO8-EFCP
Supported combinations of plug-in modules
Communication modules
CM-RS232-485 731
CM-Ethernet 733
CM-GPRS 735
CM-4G-GPS 739
CM-RS232-485
CM-RS232-485 is optional plug-in card to enable InteliLite the RS232 and RS485 communication. This is
required for computer or MODBUS connection. The CM-RS232-485 is a dual port module with RS232 and
RS485 interfaces at independent COM channels. The RS232 is connected to COM1 and RS485 to COM2.
