Hint:
In the case MCB Logic = “CLOSE-OFF” it is necessary to change externally the polarity of the output
signal.
ReturnFromTEST [MANUAL / AUTO]
The set point influences the behavior of the TEST mode.
MANUAL
:
1) Select TEST, gen-sets starts and running unloaded
2) To transfer load from mains to the gen-set press MCB ON/OFF or wait for power-cut.
3) When mains recovers, the gen-set remains running loaded.
4) To stop the gen-set select AUTO Mode
5) In AUT Mode:
a) After the
MainsReturnDel InteliLite opens the GCB
b) After the
Fwd Return Del delay InteliLite closes the MCB.
c) The gen-set is cooled and stopped
AUT
:
1) Select TEST, gen-sets starts and running unloaded
2) To transfer load from mains to the gen-set wait for the power-cut. the controller does not response
for MCB ON/OFF button.
3) When the mains recovers:
a) After the
MainsReturnDel the controller opens the GCB
b) After the
Fwd Return Del delay the controller closes the MCB.
4) The gen-set remains running.
5) To stop the gen-set select a different mode than TEST.
MCB Opens On [MAINSFAIL / GENRUN]
MAINSFAIL
The command to open the MCB is given immediately after mains fail condition evaluated.
GENRUN
The command to open the MCB is not given till the Gen-set starts (with respecting the setpoint
EmergStart Del), reaches Running state, reaches proper voltage and frequency and Min Stab Time
elapses. After that, the MCB is opened, Fwd Return Del timer is started and the GCB is closed after
the timer elapses.
Hint
:
This option should be used for MCBs using 230V control and not equipped with the undervoltage coil.
Date/Time
Time Stamp Per [min]
Time interval for periodic history records.
Step: 1 min
Range: 0 – 200min
#SummerTimeMod [ DISABLED / WINTER / SUMMER,WINTER-
S, SUMMER-S ]
DISABLED: Automatic switching between summer and wintertime is disabled.
WINTER (SUMMER) : Automatic switching between summer and wintertime is enabled and it is set to
winter (summer) season.
WINTER-S (SUMMER-S) : Modification for southern hemisphere.
#Time [HHMMSS]
Real time clock adjustment.
