IL-NT RS232 interface (optional card)
Plugs into IL-NT controller COMMUNICATIN MODULE port.
Maximal distance 10m
Speed 19.2kBd (STD) 9.6kBd (MODBUS)
Recommend external converter:
ADVANTECH – ADAM 4520: RS232 to RS422/485 converter, DIN rail, automatic RS485 bus
supervision, no external data flow control signals, galvanic isolated.
Recommended internal converter:
ADVANTECH – PCL-745B or PCL745S : Dual port RS422/485 Interface card, automatic RS485 bus
supervision, no external data flow control signals, galvanic isolated
IL-NT AOUT8 interface (optional card)
Plugs into IL-NT controller EXTENSION MODULE port.
Number of PWM outputs 8
PWM frequency 250Hz
Maximum current 0.5 A
Maximum switching voltage 36 VDC
Output resistance 1Ω
Resolution 10 bits
IGS-PTM
Voltage supply 8-36V DC
Consumption 0,1A depend on supply voltage
Mechanical dimensions: 40 x 95 x 45 mm , DIN rail (35 mm) mounted
Interface to controller CAN
Binary inputs and outputs see IG-IOM
Analog output see IG-IOM
Analog inputs
Not electrically separated
Number of inputs 4
Resolution 10 bits
Maximal resistance range 0 – 250
Ω
Maximal voltage range 0 – 100 mV
Maximal current range 0 – 20 mA
Resistance measurement tolerance 1 %
± 2 Ω out of measured value
Voltage measurement tolerance 1,5 %
± 1mV out of measured value
Current measurement tolerance 2,5 %
±0,5mA out of measured value
IGL-RA15
Power supply
Voltage supply 8-36V DC
Consumption 0,35-0,1A (+1A max horn output)
Depend on supply voltage
