InteliLite
NT
– AMF20/25, SW version 1.2, ©ComAp – March 2008 53
IL-NT-AMF-Reference Guide1.2.pdf
#Date [DDMMYYYY]
Actual date adjustment.
Timer 1..2 Repeat
[NONE/MONDAY/TUESDAY/WEDNESDAY/THURSDAY/WEDNESDAY/FRI
DAY/SATURDAY/SUNDAY/MON-FRI/MON-SAT/MON-SUN/SAT-SUN]
Defines TIMER 1 activation. Binary output TIMER 1 is internally linked with Rem Start/Stop binary
input. Refer to binary inputs for details.
NONE: Timer function is disabled
MONDAY, TUESDAY, WEDNESDAY, THURSDAY, WEDNESDAY, FRIDAY, SATURDAY, SUNDAY:
Timer is activated on daily basis.
MON-FRI, MON-SAT, SAT-SUN:
Timer is activated on selected day interval.
Timer1..2 ON Time
Day time when Timer output activates.
Timer1..2Duration
Duration of Timer output is active.
Step: 1 min
Range: 1 – 1440 s
Sensor Spec
AI1,AI2,AI3Calibration […]
Calibrating constant to adjust the measured value of IL analog inputs. Physical dimension
of calibrating constant is corresponding to Analog input.
Step: 1
Range: -1000 – +1000
Hint
:
Calibration constants have to be adjusted when measured value is near the alarm level.
User curves A, B, C can be defined by LiteEdit software.
IOM AI1..4 Calibr […]
Calibrating constant to adjust the measured value of IOM/PTM analog inputs. Physical dimension of
calibrating constant is corresponding to Analog input.
Step: 1
Range: -1000 – +1000
Fuel Pump ON [%]
When the actual value of fuel level is lower or equals to this value then the binary output Fuel Pump is
activated.
Step: 1
Range: 0 – 100 %
Fuel Pump OFF [%]
When the actual value of fuel level is higher or equals to this value then the binary output Fuel Pump
is deactivated.
Step: 1
Range: 0 – 100 %
