AI3 Sd [ ]
Shutdown threshold level for ANALOG INPUT 3
Step: 1 %
Range: -100 – 10000
AI3 Del [s]
Delay for ANALOG INPUT 3
Step: 1 s
Range: 0 – 180 s
Batt Undervolt [V]
Warning threshold for low battery voltage.
Step: 0,1 V
Range: 8V – 40 (Battery >Volts)
Batt Volt Del [s]
Delay for low battery voltage alarm.
Step: 1s
Range: 0 – 600 s
Maintenance [h]
Counts down when engine running. If reaches zero, an alarm appears.
Step: 1h
Range: 0 – 65535h
Gener Protect
Hint
:
All electric protections when activated result in shutdown.
Overload [%]
Threshold for generator overload (in % of Nominal power)
Step: 1% of Nominal power
Range: 0 – 200%
Overload Del [s]
Delay for generator overload alarm.
Step: 0.1s
Range: 0 – 600.0 s
Short Crct Sd [ % ]
Shutdown occurs when generator current reaches Short Crct Sd limit.
Step: 1 % of
Nominal current
Range: 100 - 500 %
Short Crct Del [s]
Delay for generator shorcurrent alarm.
Step: 0.01s
Range: 0.00 – 10.00 s
*Amps IDMT Del [ s ]
IDMT curve shape selection. Amps IDMT Del is Reaction time of IDMT protection for 200%
overcurrent Igen = 2*
Nomin Current.
Step: 0,1 s
Range: 0,1 - 60,0 s
