Step: 1s
Range: 0 – 300 s
Horn Timeout [s]
Max time limit of horn sounding. Set to zero if you want to leave the output HORN open. Horn timeout
starts again from the beginning if a new alarm appears before previous Horn timeout has elapsed.
Step: 1s
Range: 0 – 600 s
Overspeed [%]
Threshold for over speed protection
Step: 1% of nominal RPM
Range: 100 – 150%
Hint
:
The Overspeed protection value is increasing from 115 % to 125% of nominal RPM for the duration
of 5sec (Engine Protection delay). Engine Protection delay takes place during the start of the gen-set
when some engine protections have to be blocked. This delay starts after reaching 25% of nominal
RPM. It holds true if the value GeerTeeth = 0.
AI1 Wrn [ Bar]
Warning threshold level for ANALOG INPUT 1
Step: 0,1 bar
Range: -10 – 1000
AI1 Sd [ Bar]
Shutdown threshold level for ANALOG INPUT 1
Step: 0,1 bar
Range: -10 – 1000
AI1 Del [s]
Delay for ANALOG INPUT 1
Step: 1 s
Range: 0 – 180 s
AI2 Wrn [ ]
Warning threshold level for ANALOG INPUT 2
Step: 1
°C
Range: -100 – 10000
AI2 Sd [ ]
Shutdown threshold level for ANALOG INPUT 2
Step: 1
°C
Range: -100 – 10000
AI2 Del [s]
Delay for ANALOG INPUT 2 alarm.
Step: 1 s
Range: 0 – 180 s
AI3 Wrn [ ]
Warning threshold level for ANALOG INPUT 3
Step: 1 %
Range: -100 – 10000
