Comelit 8472MC - MSK;013 BC Branch Diagram

115
ON
ON
MSK/013BC
IT
EN
FR
NL
DE
ES
PT
2
1
1
1
A
MAX
B
MAX
C
MAX
D
MAX
Art.
1216
Comelit Art. 4576-4578 0,5 mm
2
(Ø 0,8 mm AWG 20)
25 m
(85 feet)
200 m
(655 feet)
100 m
(325 feet)
UTP5 cat. 5 0,2 mm
2
(Ø 0,5 mm AWG 24)
190 m
(625 feet)
60 m
(195 feet)
0,28 mm
2
(Ø 0,6 mm AWG 23)
5 m
(15 feet)
190 m
(625 feet)
60 m
(195 feet)
0,5 mm
2
(Ø 0,8 mm AWG 20)
25 m
(85 feet)
25 m
(85 feet)
190 m
(625 feet)
60 m
(195 feet)
1 mm
2
(Ø 1,2 mm AWG 17)
50 m
(165 feet)
50 m
(165 feet)
190 m
(625 feet)
60 m
(195 feet)
1 mm
2
(Ø 1,2 mm AWG 17)
50 m
(165 feet)
50 m
(165 feet)
120 m
(395 feet)
40 m
(130 feet)
1,5 mm
2
(Ø 1,4 mm AWG 15)
75 m
(245 feet)
100 m
(330 feet)
190 m
(625 feet)
60 m
(195 feet)
2,5 mm
2
(Ø 1,8 mm AWG 13)
100 m
(330 feet)
150 m
(495 feet)
190 m
(625 feet)
60 m
(195 feet)
2
*
Schema base per kit bifamiliari Art. 8472MC con collegamento in derivazione
*Pulsante comando apriporta locale
Per maggiori informazioni sulle distanze vedi pag. 8
Basic diagram for two-family kits Art. 8472MC with branch connection
*Local door-opener button
For further information about distances refer to page 24
Schéma base pour kit deux usagers Art. 8472MC avec connexion en dérivation
*Bouton commande ouvre-porte local
Pour plus de détails sur les distances faire référence au page 40
Basisschema voor kits voor tweegezinswoningen Art. 8472MC met afgetakte aansluiting
*Bedieningsknop lokale deuropener
Zie voor meer informatie over de afstanden pagina 56
Grundanschlussplan für Zweifamilienhaus-Sets Art. 8472MC mit Anschluss über Abzweigung
*Lokale Türöffnertaste
Siehe Seite 72 für weitere Informationen zu den Entfernungen
Esquema básico para kit bifamiliares Art. 8472MC con conexión en derivación
*Pulsador abrepuertas local
Para mayor información sobre las distancias, véase la página 88
Esquema base para kits bifamiliares Art. 8472MC com ligação em derivação
*Botão de comando abertura da porta local
Para mais informações sobre as distâncias, consultar as página 104
