Programming input IN1 for LED/alarm/lock-release/
actuator indication
Carry out steps 1 to 4
1) 2) 3) 4)
S1
DIP
1
DIP
2
DIP
3
DIP
4
DIP
5
DIP
6
S2 S1/S2/LED1
IN 1 input
LED (default), see page 126
000110
Input IN 1 ALARM, see page 126
Take note
of the S2, S1 setting
and restore it when
programming is
complete.
Input IN 1 LOCK-RELEASE, see page 126
001010
Input IN 1 CODED ACTUATOR, see page 126 set code, TAB. C on page 29
Input IN 1 GENERIC ACTUATOR, see page 126
DIP ON
S2
2 sec
