Comelit Planux - Alarm System Overview; Alarms Menu Description; Area Status Legend

54
ALARM
ALARM
Downstairs area
Downstairs area
Upstairs area
Garage
External
1
5
4
3
2
Thu 05/09/09 - 16:07 0W
To access the Alarms menu, press the icon on the
main menu screen.
ALARMS MENU DESCRIPTION
1 Available areas.
2 Scroll through the screen (only when there are
more than 4 programmed areas).
3 Alarm settings menu.
4 Full anti-intrusion system arming.
5 Full anti-intrusion system disarming / alarm
memory reset.
Downstairs area 1
Downstairs area 1
Downstairs area 2
Downstairs area 2
Downstairs area T
Downstairs area T
Downstairs area
Downstairs area
Downstairs area
Downstairs area
1
2
3
4
6
7
8
Downstairs area P
Downstairs area P
5
AREA STATUS LEGEND
1 Alarm not active.
2 Part zone 1 active.
3 Part zone 2 active.
4 Part zones 1 and 2 active.
5 All area zones active.
6 Area not ready for arming.
7 Alarm memory.
8 Area in alarm status.
