Comelit Planux - Dimmer Light Control; Dimmer Light Scheduling

9
LIGHTS
LIGHTS
The
ONON
/
OFFOFF
icon enables/disables the current
schedule.
Select the days of the week for which you wish to
program the activity (selected days will be highlighted
in red) and press the
+
icon to add a programming
schedule to the list.
00:00
+
-
x
+
1
7
6
5
2
00:00 ON
4
3
Thu 05/09/09 - 16:07 0W
STATUS
TIME
M
T
W
T
FSS
1 Days of the week selected.
2 Programming saved.
3 Add programming.
4 Delete programming.
5 Confi rm.
6 Selector keys to modify time and status.
7 Save.
Set the desired activity time using the selector keys
and press the
icon to confi rm. Select the desired
status and press
to confi rm. Set the brightness of
the light and press to confi rm. Repeat the above
steps as necessary to add several programming
schedules. To delete a programming schedule, select
it and press the
x
icon, followed by to confi rm.
When you have fi nished, press the
STOP
icon to log the
information.
DIMMER LIGHT SCHEDULING
Once you have entered the relevant area, press the
icon and then the icon corresponding to one of the
dimmer lights available (e.g. Bedroom) to access the
dimmer light scheduling menu.
1 Days of the week.
2 List of logged programming.
3 Start programing.
ON
1
3
2
Thu 05/09/09 - 16:07 0W
MM
STATUS
TIME
T
W
T
FSS
ONON
Press the
PROG
icon to access the programming screen.
x
+
Thu 05/09/09 - 16:07 0W
STATUS
TIME
M
T
W
T
FSS
