Chapter 1 Product Overview
3
1.3 Packaging Content
Thank you for purchasing the Compex Web Managed Switch CGX3224. You will find
the following items in the package:
Please note that the actual product appearance may slightly differ depending on the
hardware version.
1 x Compex CGX3224 unit
2 x brackets
6 x screws
1 x RS232 straight cable
1x Quick Install Guide with
warranty card
1 x CD-ROM
1 x Power Cord
1.4 Overall Setup Procedure
1. Hardware Installation of Compex CGX3224.
Refer to Chapter 2 “Hardware Installation” on Page 7
2. Set IP address to Static (Since the DHCP default setting for Compex CGX3224 is
disabled)
Refer to Appendix III “TCP/IP Configuration” on Page 79
3. Configure Compex CGX3224
Refer to Chapter 3 “Hyper Terminal Configuration” on Page 9 or Chapter 4
“Access to Web-based Interface” on Page 11
