Compex CGX3224 User Manual

Chapter 8 Advanced Configuration for Compex CGX3224
53
8.6 Port Security
Of all 26 ports, some of the ports may need to be assigned to one specific port. In order
to fulfill this act, MAC Address should be added to that particular port. This is to restrict
other users from using the static port. A port can accommodate up to 20 MAC
Addresses.
Procedures
1. Go to Port Security from the Command window.
2. Select a port and enter the MAC address in the field provided, e.g. 00-80-40-E8-85-
12.
3. Click on the Add button and the system will then add in the New MAC Address
into the listing on the right side of the screen.

Compex CGX3224 Specifications

General

Brand	Compex
Model	CGX3224
Category	Switch
Language	English
