Chapter 1 Product Overview
4
1.5 Network Applications
Compex CGX3224 may be used in the Backbone with an ADSL broadband internet
connection as shown in Figure 1.5a. Virtual LAN may be defined on Compex CGX3224
to logically segmentize your LAN into multiple broadcast domains with workgroup
classifications.
Figure 1.5a Compex CGX3224 in the Backbone
User groups on
Private LAN
Switching
SNMP
Manager
CGX3224
High
Bandwidth
Servers
Internet
Servers
GSC2008WM
