Chapter 1 Product Overview
5
You can connect Compex CGX3224 via the optional modules to an external Ethernet
Hub/Switch to increase the number of users for Internet access. Using a UTP network
cable, connect one end to Compex CGX3224 and the other to the network switch.
Figure 1.5b shows how Compex CGX3224 can be connected to an existing switch to
increase the Internet access for the LAN users from just one dedicated Internet access to
multiple accesses.
Figure 1.5b Compex CGX3224 installed with optional fiber optic module
Building B
Building C
Building A
Gigabit Ethernet on
Fiber (1000 Base-SX) or
Fast Ethernet on Fiber
(100 Base-FX)
CGX3224 Unit #1
CGX3224 Unit #2
CGX3224 Unit #3
To Next Page
