Compex CGX3224 User Manual

Appendix I Panel Views & Descriptions
74
Appendix I Panel Views & Descriptions
Please note that the actual product appearance may slightly differ depending on the hardware
version.
Figure 11.1a Front Panel View of Compex CGX3224
Figure 11.1b Front Panel View of Compex CGX3224 (Section #1)
Figure 11.1c Front Panel View of Compex CGX3224 (Section #2)
1 2
7 8 6 9 3 4 5
10 11
