Chapter 5 Configure Compex CGX3224 using Web Interface
22
Subnet Mask
This is the Subnet Mask to identify the class of the Gateway’s
IP address. By default, Class C Subnet Mask 255.255.255.0 is
set. The users may configure the network with Class A
(255.0.0.0) and Class B (255.255.0.0) Subnet Mask as well. In
addition, Compex CGX3224 can be configured for Classless
Subnet to support certain applications.
DHCP Start IP
Address & DHCP
End IP Address
These parameters specify the range of the IP addresses of
which the DHCP Server will assign.
Primary DNS IP
Address &
Secondary DNS IP
Address
DNS is an Internet service that translates domain names into
IP addresses. If your WAN connection uses Static IP, you
should configure the primary and secondary DNS IP
addresses with the DNS information provided by your
Broadband Internet Service Provider. For other WAN
connection types, the DNS IP addresses are automatically
obtained from the ISP. The “Always use these DNS servers:”
checkbox can be used to disable the automatic process, and
your preferred DNS IP addresses can be used.
DHCP Server
DHCP server dynamically assigns IP addresses to the PCs
connected in the same network. DHCP comes with a built-in
DHCP server that automatically assigns IP addresses, DNS
and Gateway information to the computers connected in the
same network. It has been pre-configured with IP address and
Subnet Mask of 192.168.100.128 and 255.255.255.0
respectively.
Procedures
1. Go to DHCP Config from the Command window.
2. Enter the values for IP Address, Subnet Mask, DHCP Start and End IP
Addresses to individual fields.
3. You can check on Always use these DNS servers: to disable the function of
retrieving DNS IP Address automatically, so that you can enter your preferred DNS
IP Address in the Primary and Secondary DNS IP Address field.
4. Next, you can set DHCP Server to Enable if you wish to use the built-in DHCP
server of Compex CGX3224.
5. Click on Save button to save your configuration.
