Chapter 9 Using SYSTEM TOOLS Menu
61
3. You may go to WAN Config to check for your WAN port’s IP address.
NOTE
You need to set the gateway of your Compex CGX3224 to 0.0.0.0 in order to
allow WAN access from your home.
4. Go to System Config from the Command
window. Ensure that your gateway is set to
0.0.0.0.
5. Click Save button to update the changes.
6. Next, from your home’s PC, open your Internet browser, enter this IP address
203.120.12.12:50 in the address bar, where 203.120.12.12 is WAN port’s IP address
of Compex CGX3224; and 50 is the http port.
NOTE
At any one time, the switch can be managed by only one user from either
LAN or WAN. Concurrent switch management by multiple users is
prohibited.
