Appendix II Specifications
78
LED Indicators • Power
• Link
• Activity
• Mode
• Speed (10/100/1000Mbps)
• Duplex status
Operation Mode • N-Way Auto-negotiation
• Force Mode
Transmission Mode • Full Duplex
• Half Duplex
Optional Modules • 100Base-FX
• 1000Base-SX
Power Supply • Internal power supply is provided with voltage ratings of
100 V AC to 240 V AC, 50~60 Hz
• Power consumption is 40 W maximum.
Environment Requirements Operating Temperature:
Storage Temperature:
Operating Humidity:
Storage Humidity:
0°C to 40°C
-20°C to 70°C
10% to 80% RH
5% to 90%
RH=Relative Humidity
MAC Address Table 4K
Packet Buffer 24Mbytes
Back Plane Capacity 12Gbps
Physical Dimension 440mm x 200mm x 44mm (L x B x H)
