Comtech EF Data CSAT-5060 - Figure 8-2 TX;RX Filter Support Bracket, AS;0502

C-Band Transceiver Revision 1
LNA Installation MN/CSAT5060.IOM
8–3
Item Part No. Nomenclature QTY
1 FP/BR0085 Bracket, Support, TX/RX Filter 1
2 M6 Lockwasher M6 Lockwasher 12*
3 HW/M6X1X25MM Bolt, Hexhead 12*
4 M6 Flatwasher M6 Flatwasher 12*
* Note: Quantity may vary
Figure 8-2 TX/RX Filter Support Bracket, AS/0502
