Comtech EF Data CSAT-5060 - Figure 8-3. Waveguide Kit, CPR229, AS;0461

C-Band Transceiver Revision 1
LNA Installation MN/CSAT5060.IOM
8–4
(For mounting customer-supplied unit to LNA assembly)
Item Part No. Nomenclature QTY
1 HW/M6X1X30MMHEX Bolt, Hexhead M6 12
2 GA/GSKTCPR229HALF Gasket, CPR229, Half-Thick 1
3 HW/M6X1HEXNUT Nut, Hex M6 12
4 HW/M6LOCK Washer, Lock M6 12
5 GA/GSKTCPR229FULL Gasket, CPR229, Full-Thick 1
6 HW/M6FLAT Washer, M6 Flat 24
Figure 8-3. Waveguide Kit, CPR229, AS/0461
