CSAT-5060 C-Band Transceivers Revision 1
Appendix A MN/CSAT5060.IOM
A–19
CSAT Remote Commands
Parameter
Type Command Arguments Description of arguments
Response to
Command Query
Response to
Query
Concise
Configuration
Status
N/A
31 bytes,
alpha numerical
Query only.
Used to Query the Configuration status of the CSAT
Example: CCS=uuuu.udddd.daa.aabb.bbotamrncfx’cr’’lf’
where:
uuuu.u = TX frequency
dddd.d = RX frequency
aa.aa = TX attenuation
bb.bb = RX attenuation
o = online status, 0 = OFFLINE, 1 = ONLINE
t = transmitter status, 0 = OFF, 1 = ON
a = amplifier status, 0 = OFF, 1 = ON
m = TX mute status, 0 = Unmuted, 1 = Muted
r = receiver status, 0 = OFF, 1 = ON
n = RX mute status, 0 = Unmuted, 1 = Muted
c = cold start, 0 = Disabled, 1 = Enabled
f = auto fault recover, 0 = Disabled, 1 = Enabled
x = external reference present, 0 = NO, 1 = YES
N/A CCS? CCS=x….x
See Note 2
Concise LNA
Status
N/A
4 bytes,
alpha numerical
Query only.
Used to Query the LNA status of the CSAT
Example: CLS=abbc’cr’’lf’
where:
a = LNA Current 0=OFF, 1=ON
bb = Current window in %
c = LNA Fault Logic 0=OFF, 1=ON
N/A CLS? CLS=x….x
See Note 2
Concise Utility
Status
N/A
10 bytes,
alpha numerical
Query only.
Used to Query the Utility status of the CSAT
Example: CUS=brrru.ud.d’cr’’lf’
where:
b = baud rate, 1 = 1200, 2 = 2400,
3 = 4800, 4 = 9600, and 5 = 19200
rrr = reference adjust
u.u = Up converter slope adjust
d.d = Down converter slope adjust
N/A CUS? CUS=x….x
See Note 2
