C-Band Transceiver Revision 1
CSAT-5060 5 to 25 Watt Installation MN/CSAT5060.IOM
A–17
Item Part No. Nomenclature QTY
1 SW/COAX-N-F-Sealed Switch COAX N-FE 1
2 RF/WG9605 Attenator, Modification 1
3 HW/M4X.07X8MMPHMS Screw, Panhead 4
4 HW/M4LOCK Washer, Lock 4
Figure A-18. TX/Remote Switch Assembly, AS/0503
