Comtech EF Data CSAT-5060 - Redundancy Configuration; Mounting Kit

C-Band Transceiver Revision 1
CSAT-5060 100/125 Watt Installation MN/CSAT5060.IOM
C–9
C.5 REDUNDANCY CONFIGURATION
C.5.1 Mounting Kit
Table C-2. Final 1:1, C-Band Assembly
Part No. Nomenclature QTY
AS/0438 Kit, LNA Mounting 1
AS/0460 Kit, Waveguide CPR137G 1
AS/0461 Kit, Waveguide CPR229 1
AS/0478 Switch, Waveguide, TX 1:1 1
AS/0490 Assy, Remote Switch Box 1
AS/TBD
Cable Kit (See Fig. 2-12) 1
Table C-3. 1:1 Mounting Assembly, AS/0598
Part No. Nomenclature QTY
*AS/0414 Redundancy Kit, Pole Mount 2
*AS/0415 Single-Thread Mounting Kit 2
AS/0479 Switch, Mount Kit TX 1
*Refer to Single Thread Configuration.
