C-Band Transceiver Revision 1
CSAT-5060 100/125 Watt Installation MN/CSAT5060.IOM
C–10
Item No. Part No. Nomenclature QTY
1 FP/BR0066 Bracket, Switch Mounting 1
2 HW/M8FLATSS Washer, Flat M8, SS, Metric 4
3 HW/M5FLAT Washer, Flat SS Metric 8
4 HW/M5LOCK Washer, Lock SS, Metric 4
5 Not Used
6 HW/M8SPRINGNUT Springnut, M8 X 1.25 4
7 HW/M8X1.25X25HEXSS Bolt, Hex Head, M8 X 1.25 X 25 SS 4
8 FP/BR0082 Bracket, Switch Mounting 1
9 HW/M5X.O8HEXNUT Nut, Hex 4
10 HW/M5LOCKSS Washer, Lock SS, Metric 4
11 HW/M5X.08X15MMHEX Bolt, Hex Head 4
Figure C-8. TX Switch Mounting Kit, AS/0479
