CSAT-5060 C-Band Transceiver Revision 1
Ethernet-based Remote Product Management MN/CSAT5060.IOM
AA–23
AA.5.5.3.4 Config | Utility Page
Use this page to configure Utility operating parameters for the unit. At any time, click Refresh to
update this page and see the most recent data.
Figure AA-9. Config | Utility page
Date and Time
Enter the Date and/or the Time:
Field Format Minimum Value Maximum Value
Date (MM/DD/YY)
Month 01 12
Day 01 31
Year 00 99
Time (HH:MM:SS)
Hours 00 23
Minutes 00 59
Seconds 00 59
Click Change Date/Time to save the settings.
Circuit ID
Enter a Circuit ID string of up to 24 characters. Click Change CID to save the string.
Current SC/13320 Active Firmware Image # (read-only)
This example identifies Image 2 as the Current Active Firmware Image.
Next Reboot Image – Use the drop-down list to select the Next Reboot Image as 1 or 2, and
then click Submit to save the setting.
